ML180-EU-CH-12V - Electrified Mortise Lock - Schlage L-Series Retrofit - 12V Fail Secure Storeroom Function

Product Description

Overview

The Command Access ML180‑EU‑CH‑12V is a 12V electrified mortise lock chassis from the ML1 series, built as a direct retrofit for Schlage L-Series hardware. Designed for storeroom function with fail secure operation, this chassis provides a reliable and power-efficient solution for secure access control in commercial settings.

Specifications

• Product Type: Electrified Mortise Lock Chassis

• Series: ML1 – Schlage L-Series Retrofit

• Electrified By: Command Access Technologies

• Model: ML180‑EU‑CH

• Voltage: 12 VDC

• Function: Storeroom (EU – electronically unlocked)

• Operation: Fail Secure – outside lever remains locked when power is lost

• Power Requirements:

  • Amperage: 700 mA

  • Solenoid resistance: 18 Ω

  • Power consumption: 8 watts

• Power Compatibility: Accepts 12VAC/DC (±10%) via plug-in bridge rectifier

• Handing: Field reversible (EL/EU configurable)

• Solenoid: Continuous duty rated

• Warranty: 3-year no-hassle Command Access warranty

Features & Benefits

• Electrified by Command Access: Purpose-built for Schlage L-Series trim retrofits

• Storeroom Functionality:

  • Outside lever unlocked electronically

  • Latchbolt retracted via key or inside lever

  • Inside lever always active for free egress

• Fail Secure Design: Keeps door locked during power interruptions

• Efficient & Durable: Grade 1 construction and low current draw

• Flexible Installation: Reversible handing and EL/EU conversion in the field

• Access Control Ready: Works with standard 12VDC access systems

Common Applications

• Classrooms and administrative offices

• Building entry doors

• IT rooms and secure areas

• Lobby and corridor access points

• Retrofit projects using Schlage L-Series hardware
