Command Access CLN80PDEU RHO 12V 626 – Electrified Schlage ND80 Cylindrical Lock, Rhodes Lever, Satin Chrome with Cylinder
Product Description
The Command Access CLN80PDEU RHO 12 V 626 is an electrified cylindrical lock based on the Schlage ND80 mechanical chassis and factory-electrified by Command Access Technologies. Outfitted with the timeless Rhodes-style (RHO) lever and a 626 satin chrome finish, this fail-secure lock includes a factory-installed Schlage C keyway cylinder for complete key access. Ideal for stairwells, classrooms, corridors, or any secure commercial opening, this lock enables controlled access via 12V systems.
Specifications
-
Model: CLN80PDEU RHO 12 V 626
-
Function: Electrified cylindrical lock, Fail-Secure (unlocks when powered)
-
Finish: 626 Satin Chrome
-
Lever Style: Rhodes (RHO)
-
Includes: Schlage C keyway 6-pin cylinder (pre-installed)
-
Voltage: 12 V AC/DC (±10%)
-
Current Draw: 250 mA @ 12 V
-
Power Consumption: 3 W
-
Solenoid Coil Resistance: 49 Ω
-
Compatibility: Fits Schlage ND80 door preps
-
Bridge Rectifier: Included for AC/DC flexibility
-
Warranty: 3-Year limited (Command Access)
Features and Benefits
-
Original Schlage ND80 mechanical lock, electrified by Command Access
-
Fail-secure operation for power-loss security
-
Clean Rhodes lever design pairs with professional satin chrome finish
-
Compatible with AC or DC power via plug-in bridge rectifier
-
Easy retrofit for existing ND installations with no door modifications
-
Solenoid rated for continuous-duty cycles (suitable for constant-on)
-
Ready for access control integration in schools, offices, healthcare, and more
Additional Information
This unit combines Schlage's trusted ND80 platform with Command Access electrification, offering seamless access control integration while maintaining mechanical strength and key compatibility. A complete solution for high-use doors requiring secure and flexible entry management.
